9YG-2.2 Round Baler is a high-tech product in modern agriculture and animal husbandry, which is mainly used for harvesting cut and dried pasture and stalks such as rice straw, wheat straw and corn straw. This machine realizes mechanized operation in the process of packing straw, pasture and other materials. The bales rolled by the round baler have high density, tight outside and loose inside, the outer layer is heat-insulated and moisture-proof, and the inner layer is well ventilated, which is convenient for storage.

1.The new generation pickup system is composed of new type spring teeth, narrow retainer, non-cam type high speed pickup, thickened conveyor and spiral arrangement welded forced feeder, and has high working efficiency.
2.To adjust the opening and returning of the bottom bin by controlling the terminal so as to solve the problem of blocking grass.
3.The profiling wheel of pickup can adapt to all kinds of complex terrain and has good field passing ability.
4.The rolled bales have high density, tight outside and loose inside, the outer layer is heat-insulated and moisture-proof, and the inner layer is well ventilated, which is convenient for storage.
5.Fully automatic self-lubricating system, one-button start, intelligently lubricating related bearings and chains.
6.Intelligent production line to finish parts production and machine assembly, stable performance and low failure rate.

Main Technical Parameters

Item		Unit	9YG-2.2	9YG-2.2B
Power		kw	≥81(110Hp）	≥81(110Hp）
Pickup Structure		/	Spring-tooth	Spring-tooth
Overall Dimensions (LxWxH)		mm	4300x3150x2600	4300x3150x2600
Weight		kg	3900	4300
Speed of Power Output Shaft		rpm	540	540
Width of Pickup Chamber		mm	2210	2210
Dimension of Compression Chamber	Diameter	mm	1250	1250
	Length		1230	1400
No. of Rows of Spring Tooth		/	6	6
Space between Spring Teeth		mm	70	70
No. of Blades		Pcs	12	12
Theoretical Cutting Length		mm	65	65
Operating Speed		km / h	2-6	2-6
Bale Weight		kg	Stalk≥350	Stalk≥350
			Forage grass≥350	Forage grass≥350
